APPLICATION:

Used to test that the upper skin of shoes is squeezed, stretched and twisted during walking.  Wrinkle, crease or damage of vamp skin.

STANDARDS: SATRA PM25,ISO-5423 etc.

Instrument characteristics:

1. Touch screen display, user-friendly interface design and easy operation.

2. The surface of the instrument is treated by electrostatic spraying process.

3. The instrument is designed as a desktop computer with stable operation and low noise.

4. The core transmission mechanism adopts imported precision guide rails.

5. The panel is made of special aluminum and has metal keys, which are sensitive to operation and not easy to damage.

Technical indicators:

1. Telescopic distance: 19±0.5mm

2. Expansion and contraction speed: 300±30cpm

3. Specimen size: 64x64mm

4. Number of samples: 12pcs

5. fixture: 40°V V-shaped V-shape 6.4 mm (R)

6. Power supply: AC 220V,2A

7. Volume: about 550 x 350x300 mm

8. Weight: about 60kg
